SoaringE Super Mini Thermal Printer for Arduino DIY Development

Specifications:

• Material Semi-soft fiber FR4, plastic + iron housing
• Compatible with kinds of controller serial port printer
• compatible with Arduino / Freaduino; The master control board and development board with serial port can be used; compatible with computer; It can print different size character, bar, image, convenient to use
• If you want to use Freaduino to drive the printer, you do not need the DC jack, you can directly use ex-power adapter and use VIN power supply for printer; Requires 2.25" wide, 50 ft or shorter thermal paper; Requires DC 5~9V @ 1.5Amp power supply during printing; Printing Speed: 50~80mm/s;
• Resolution: 8 dots/mm, 384 dots / line; Effective Printing Width: 48mm; Character Set: ASCII, GB2312-80 (Chinese); Print Font: ANK: 5 x 7, Chinese: 12 x 24, 24 x 24; Paper Type: Thermal paper Paper Width: 57.5 +/- 0.5mm; Paper Roll Diameter: max 39mm; Protocol: TTL Serial, 19200 baud Mean Cycles Before Failure: 5 million lines; Power Supply (Adapter): DC 5~9V; Operating Temp: 5'C~50'C; Operating Humidity:
